MF52A682J3470
Product Overview
- Category: Electronic Component
- Use: Temperature Sensor
- Characteristics: High precision, small size, wide temperature range
- Package: SMD (Surface Mount Device)
- Essence: Accurate temperature measurement
- Packaging/Quantity: 1000 pieces per reel
Specifications
- Resistance at 25°C: 6.8kΩ
- Tolerance: ±5%
- Temperature Range: -40°C to 125°C
- Thermal Time Constant: ≤7s
- Operating Voltage: 3V to 5V
- Power Rating: 45mW
Detailed Pin Configuration
The MF52A682J3470 has two pins: 1. Pin 1: Connects to the ground 2. Pin 2: Connects to the input/output for temperature measurement
Functional Features
- Accurate temperature sensing
- Small size for easy integration into electronic devices
- Wide operating temperature range
- Fast response time
Advantages and Disadvantages
Advantages
- High precision temperature measurement
- Compact size for space-constrained applications
- Wide temperature range suitable for various environments
Disadvantages
- Tolerance of ±5% may not be suitable for ultra-precise applications
- Limited thermal time constant compared to some alternatives
Working Principles
The MF52A682J3470 operates based on the principle of resistance change with temperature. As the temperature changes, the resistance of the sensor varies, allowing for accurate temperature measurement.
Detailed Application Field Plans
The MF52A682J3470 is ideal for use in various applications, including: - Consumer electronics - Automotive systems - Industrial equipment - Medical devices - HVAC (Heating, Ventilation, and Air Conditioning) systems
Detailed and Complete Alternative Models
Some alternative models to the MF52A682J3470 include: - NTC thermistors from other manufacturers such as EPCOS, Vishay, and Murata - Silicon-based temperature sensors like the LM35 and TMP36 - Platinum RTD (Resistance Temperature Detector) sensors for higher precision applications
In conclusion, the MF52A682J3470 temperature sensor offers high precision and a wide temperature range, making it suitable for diverse applications in various industries.
[Word Count: 320]
Enumere 10 preguntas y respuestas comunes relacionadas con la aplicación de MF52A682J3470 en soluciones técnicas
What is the application of MF52A682J3470 in technical solutions?
- MF52A682J3470 is a type of NTC thermistor commonly used for temperature sensing and control in various technical applications.
How does MF52A682J3470 work as a temperature sensor?
- MF52A682J3470 operates based on the principle of resistance change with temperature, allowing it to accurately measure and respond to changes in temperature.
What is the temperature range for MF52A682J3470?
- The MF52A682J3470 has a specific temperature range within which it can effectively sense and control temperatures, typically ranging from -55°C to 125°C.
Can MF52A682J3470 be used in automotive applications?
- Yes, MF52A682J3470 is suitable for use in automotive applications such as engine temperature monitoring and climate control systems.
Are there any precautions to consider when using MF52A682J3470 in technical solutions?
- It's important to ensure proper calibration and protection against moisture and mechanical stress to maintain the accuracy and reliability of MF52A682J3470.
What are the typical circuit configurations for integrating MF52A682J3470 into technical solutions?
- MF52A682J3470 can be incorporated into various circuit configurations, including voltage divider circuits and Wheatstone bridge arrangements, depending on the specific application requirements.
Is MF52A682J3470 compatible with microcontrollers and digital interfaces?
- Yes, MF52A682J3470 can be interfaced with microcontrollers and digital interfaces through analog-to-digital converters (ADCs) for digital temperature monitoring and control.
Can MF52A682J3470 be used in medical equipment and devices?
- Yes, MF52A682J3470 can be utilized in medical equipment for temperature monitoring and regulation, provided that it meets the necessary regulatory standards.
What are the key advantages of using MF52A682J3470 in technical solutions?
- Some advantages include high sensitivity, fast response time, compact size, and compatibility with various electronic systems.
Where can I find detailed technical specifications and application notes for MF52A682J3470?
- Detailed technical specifications and application notes for MF52A682J3470 can be obtained from the manufacturer's datasheets, application guides, and technical support resources.
